Xerox Phaser 6600 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-205
092-670 Yellow Patch Error
092-671 Magenta Patch Error
Step Check Yes No
Possible causative parts:
• Yellow Imaging Unit (PL8.1.2)
• Yellow Toner Cartridge (PL5.1.8)
• MCU Board (PL18.1.13)
1 Check after reinstalling the Toner Cartridge
Pull out and shake the Yellow Toner Cartridge, and then
reinstall it.
Does the error still occur?
Go to step 2. Finished.
2 Check after replacing the Toner Cartridge
Replace the Yellow Toner Cartridge.
Does the error still occur?
Go to step 3. Finished.
3 Check the Imaging Unit installation
Take out the Yellow Imaging Unit.
Is the connection part of the Yellow Imaging Unit clean?
And, is the Yellow Imaging Unit touching against the guides
on the left and right sides, and installed properly?
Go to step 4. Clean the
connection part.
Reinstall the
Yellow Imaging
Unit.
4 Check after replacing the Yellow Imaging Unit
Replace the Yellow Imaging Unit.
Does the error still occur?
Replace the MCU
Board.
Finished.
Step Check Yes No
Possible causative parts:
• Magenta Imaging Unit (PL8.1.3)
• Magenta Toner Cartridge (PL5.1.9)
• MCU Board (PL18.1.13)
1 Check after reinstalling the Toner Cartridge
Pull out and shake the Magenta Toner Cartridge, and then
reinstall it.
Does the error still occur?
Go to step 2. Finished.
2 Check after replacing the Toner Cartridge
Replace the Magenta Toner Cartridge.
Does the error still occur?
Go to step 3. Finished.
3 Check the Imaging Unit installation
Take out the Magenta Imaging Unit.
Is the connection part of the Magenta Imaging Unit clean?
And, is the Magenta Imaging Unit touching against the
guides on the left and right sides, and installed properly?
Go to step 4. Clean the
connection part.
Reinstall the
Magenta
Imaging Unit.

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
