Xerox Phaser 6600 Service Manual

Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-204
091-920 DRUM Y CRUM Data Broken Fail
091-960 IOT X CRUM ID Error (Y DRUM)
091-922 DRUM M CRUM Data Broken Fail
091-961 IOT X CRUM ID Error (M DRUM)
091-923 DRUM C CRUM Data Broken Fail
091-962 IOT X CRUM ID Error (C DRUM)
Step Check Yes No
Possible causative parts:
• Yellow Imaging Unit (PL8.1.2)
1 Check the Imaging Unit installation
Is an Imaging Unit other than a Yellow Imaging Unit
installed?
Or, is the installed Imaging Unit for another printer?
Install the right
Yellow Imaging
Unit.
Reinstall the
Yellow Imaging
Unit.
Step Check Yes No
Possible causative parts:
• Magenta Imaging Unit (PL8.1.3)
1 Check the Imaging Unit installation
Is an Imaging Unit other than a Magenta Imaging Unit
installed?
Or, is the installed Imaging Unit for another printer?
Install the right
Magenta
Imaging Unit.
Reinstall the
Magenta
Imaging Unit.
Step Check Yes No
Possible causative parts:
• Cyan Imaging Unit (PL8.1.3)
1 Check the Imaging Unit installation
Is an Imaging Unit other than a Cyan Imaging Unit
installed?
Or, is the installed Imaging Unit for another printer?
Install the right
Cyan Imaging
Unit.
Reinstall the
Cyan Imaging
Unit.

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
