Xerox Phaser 6600 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-203
091-919 IOT C Drum Comm Fail
091-915 DRUM UnitK CRUM Data Broken Fail
091-963 IOT X CRUM ID Error (K DRUM)
Step Check Yes No
Possible causative parts:
• Cyan Imaging Unit (PL8.1.4)
• CRUM Connector Assembly (PL8.1.1)
• MCU Board (PL18.1.13)
1 Check the Imaging Unit installation
Is the connection part between the CRUM and the CRUM
Connector Assembly inside the Cyan Imaging Unit clean
(without any foreign objects)?
And, is the Cyan Imaging Unit installed properly?
Go to step 2. Reinstall the
Cyan Imaging
Unit.
2 Check the Imaging Unit CRUM
Is the connection terminal of the CRUM inside the Cyan
Imaging Unit broken?
Replace the Cyan
Imaging Unit.
Go to step 3.
3 Check the CRUM Connector Assembly
Is the connection terminal of the CRUM Connector Assembly
broken?
Replace the
CRUM Connector
Assembly.
Go to step 4.
4 Check the CRUM Connector Assembly connection
Check the connection between the CRUM Connector
Assembly and the MCU Board.
Are P/J123 and P/J12 connected securely?
Go to step 5. Connect P/J123
and P/J12
securely.
5 Check the continuity between the CRUM Connector
Assembly and the MCU Board
Is each cable of P/J123<=>P/J12 continuous?
Replace the MCU
Board.
Replace the
CRUM Connector
Assembly.
Step Check Yes No
Possible causative parts:
• Black Imaging Unit (PL8.1.5)
1 Check the Imaging Unit installation
Is an Imaging Unit other than a Black Imaging Unit
installed?
Or, is the installed Imaging Unit for another printer?
Install the right
Black Imaging
Unit.
Reinstall the
Black Imaging
Unit.

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
