Image Quality
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
3-15
Ghosting
Possible causative parts
•Imaging Unit Y/M/C/K (PL8.1.2/PL8.1.3/PL8.1.4/PL8.1.5)
• Transfer Belt Assembly (PL6.1.1)
Action Yes No
1 If you are using non-recommended print media, switch to the print
media recommended for the printer.
Does this solve your problem?
The task is
complete.
Go to action 2.
2 Replace the Imaging Units.
Does this solve your problem?
The task is
complete.
Go to action 3.
3 Adjust the Transfer Belt Offset.
Decrease the K Offset or YMC Offset as appropriate. Refer to
“Adjusting the Transfer Belt Offsets” on page 6-22.
Does this solve your problem?
The task is
complete.
Go to action 4.
4 Check the installation status of the Transfer Belt Assembly.
Is the Transfer Belt Assembly HV terminal clean, and is it contacted
to the spring correctly?
Go to action 5. Clean the HV
terminal.
Reinstall the
Transfer Belt
Assembly.
5 Replace the Transfer Belt Assembly.
Does the problem persist even after the Transfer Belt Assembly is
replaced with a new one?
Contact Xerox
Te ch ni ca l
Support.
The task is
complete.
