Xerox Phaser 6600 Service Manual

Wiring
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
7-3
38 J-163 Connects MCU Board and Exit Clutch2 (Exit Drive Assembly)
39 J-164 Connects MCU Board and Regi Harness Assembly
40 B-158 Connects LVPS and Top Harness Assembly
40 J-163 Connects MCU Board and Exit Clutch1 [Exit Drive Assembly]
41 B-157 Connects LVPS and Rear Interlock Switch
42 B-157 Connects LVPS and Front Interlock Switch
43 B-158 Connects LVPS and Top Harness Assembly
47 H-157 Connects LVPS and Heater Harness Assembly
48 H-158 Connects LVPS and SW Harness Assembly
101 D-164 Connects IP Board and Main Harness Assembly
111 D-165 Connects IP Board and Laser Unit Video Harness Assembly
112 H-139 Connects Laser Unit and Laser Unit Video Harness Assembly
121 G-138 Connects Imaging Unit CRUM Y and X CRUM Harness Assembly
122 F-139 Connects Imaging Unit CRUM M and X CRUM Harness Assembly
123 F-139 Connects Imaging Unit CRUM C and X CRUM Harness Assembly
124 E-140 Connects Imaging Unit CRUM K and X CRUM Harness Assembly
131 I-152 Connects CTD Sensor Assembly and Regi Harness Assembly
132 G-152 Connects inside CTD Sensor Assembly
141 F-108 Connects Dispenser Motor (YM) and Upper Dispenser Motor Assembly
144 G-109 Connects Dispenser Motor (CK) Motor and Upper Dispenser Motor Assembly
145 H-109 Connects Front Cover Sensor and Upper Dispenser Motor Assembly
151 F-122 Connects Sensor Harness Assembly and Sensor Harness Assembly
154 F-122 Connects Full Stack Sensor and Exit Sensor Harness Assembly
155 E-122 Connects Exit Sensor and Exit Sensor 2 Harness Assembly
171 E-108 Connects Main Motor and Drive Harness Assembly
172 E-110 Connects Paper Transport Motor and Drive Harness Assembly
181 I-171 Connects Development HVPS Board and MCU-HVPS Flat Flex Connector (FFC)
182 H-173 Connects Development HVPS Board and HVPS Harness Assembly
191 F-136 Connects Toner CRUM Y and Top Harness Assembly
192 F-137 Connects Toner CRUM M and Top Harness Assembly
193 G-137 Connects Toner CRUM C and Top Harness Assembly
P/J Coordiates Remarks

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
