Wiring
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
7-4
194 G-138 Connects Toner CRUM K and Top Harness Assembly
203 G-153 Connects Toner Full Sensor and Top Harness Assembly
211 J-124 Connects Bypass Tray Sensor and Bypass Tray Harness Assembly
212 H-123 Connects Bypass Tray No Paper Sensor and Bypass Tray Harness Assembly
213 F-110 Connects Take Away Clutch 2 and Bypass Tray Harness Assembly
214 I-125 Connects Bypass Tray Feed Solenoid and Bypass Tray Harness Assembly
232 D-124 Connects Regi Sensor and Regi Harness Assembly
233 E-125 Connects CST No Paper Sensor and Regi Harness Assembly
234 D-126 Connects Regi Clutch and Regi Harness Assembly
251 G-111 Connects EEPROM XPRO PWB and Main Harness Assembly
271 F-112/I-182 Connects Feeder Drawer 1 Harness Assembly and Main Harness Assembly
271 I-182 Connects Feeder Drawer 1 Harness Assembly and Main Harness Assembly
281 E-152 Connects Fuser and Heater Harness Assembly
311 E-108 Connects Main Motor and Top Harness Assembly
312 E-111 Connects Paper Transport Motor and Top Harness Assembly
331 E-109 Connects Deve Motor and Drive Harness Assembly
392 E-126 Connects CST Feed Clutch and Regi Harness Assembly
402 C-166 Connects IP Board and Top Harness Assembly
403 C-166 Connects IP Board and Top Harness Assembly
419 G-183 Connects 550 Option Feeder Board and Feeder Drawer 1 Harness Assembly
420 G-183 Connects 550 Option Feeder Board and C2 Turn Harness Assembly
421 F-183 Connects 550 Option Feeder Board and C2 Size Harness Assembly
422 F-183 Connects 550 Option Feeder Board and Feeder Motor Harness Assembly
423 G-183 Connects 550 Option Feeder Board and Feeder Drawer 2 Harness Assembly
431 H-140 Connects Laser Unit and Top Harness Assembly
501 C-157 Connects LVPS and Top Harness Assembly
503 C-157 Connects LVPS and Main Fan
504* B-158 Connects LVPS and Top Harness Assembly
505* B-159 Connects LVPS and Top Harness Assembly
507 H-157 Connects LVPS and Top Harness Assembly
508 H-157 Connects LVPS and Top Harness Assembly
P/J Coordiates Remarks

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
