Xerox Phaser 6600 Service Manual

Wiring
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
7-5
509 B-158 Connects LVPS and Top Harness Assembly
1821 C-173 Connects Transfer HVPS and HVPS Harness Assembly
4201 E-184 Connects C2 Turn Clutch and C2 Turn Harness Assembly
4202 E-184 Connects No Paper Harness Assembly and C2 Turn Harness Assembly
4203 D-182 Connects C2 No Paper Sensor and No Paper Harness Assembly
4211 I-183 Connects CST Size Switch and C2 Size Harness Assembly
4212 D-182 Connects C2 Regi Sensor and Preregi Sensor Harness Assembly
4213 E-184 Connects C2 Feed Clutch and C2 Size Harness Assembly
4214 E-184 Connects Preregi Sensor Harness Assembly and C2 Size Harness Assembly
4221 F-183 Connects Option Feeder Motor and Feeder Motor Harness Assembly
281-S E-152 Connects Fuser and Fuser Harness Assembly
CN1 F-108 Connects Control Panel Assembly and Control Panel Harness
P/J Coordiates Remarks

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
