Xerox WorkCentre 5230A User Manual

15 Problem Solving
398
016-701 An error occurred due to insufficient memory for the PCL decomposer. Lower
the resolution if possible.
016-702 A page compression error occurred. The machine could not compress any page
due to insufficient free space in the buffer. Change the [Print Mode] setting to
[High Speed], or add memory to increase the page buffer size.
016-703 An e-mail specifying a non-registered or invalid mailbox number was received.
When sending a fax or Internet Fax:
• Contact the Xerox Welcome Center.
When receiving e-mail, fax, or Internet Fax:
• Register the mailbox with the specified number.
• Send an e-mail to a valid mailbox.
• Contact the Xerox Welcome Center if the problem persists.
016-704 The hard disk runs out of space, because the mailboxes are full. Delete
unnecessary documents from the mailboxes.
016-705 The Secure Print, Save to Mailbox, or Charge Print data was not stored in the
mailbox, or the data scanned on the machine was not stored in the mailbox. The
probable causes are as follows:
• The optional kit is not installed on the machine.
• The print driver is not for the machine.
Contact the Xerox Welcome Center if the problem persists.
016-706 The hard disk ran out of space, because the number of Secure Print users
reached its maximum. Delete unnecessary Secure Print jobs from the machine.
016-707 The Sample Print feature is not available due to a malfunction of the hard disk.
Contact the Xerox Welcome Center.
016-708 An annotation cannot be added due to insufficient hard disk space. Delete
unnecessary documents from the disk.
016-710 The Delayed Print job could not be executed. Take one of the following actions:
• Delete unnecessary data from the hard disk to increase free space.
• Reset the settings of Save to Mailbox and Sample Print.
• Reduce the number of stored Delayed Print jobs to less than 100 jobs.
016-711 Refer to 016-985.
016-712 Refer to 003-751.
016-713 The entered mailbox passcode is not correct. Enter the correct passcode.
016-714 The specified mailbox does not exist. Create a new mailbox or specify an
existing mailbox.
016-716 The TIFF file could not be spooled as the size of the file exceeded the remaining
space on disk. Increase the size of the PCL form area.
016-717 A [Transmission Report - Job Undelivered] or [Activity Report] was requested,
but the information was not in memory. Take one of the following actions:
• Divide Internet Fax document pages to reduce the size of a job, to increase
memory and HDD’s free space.
• Execute a new scan job or an Internet Fax job after scan and Internet Fax
jobs stored in the memory space are finished.
• Output a report before 200 or more jobs are logged.
016-718 Unable to process PCL print data due to insufficient memory. Take one of the
following actions:
• Lower the resolution.
• Cancel the Multiple-Up or 2 Sided Print feature, and try again.
Code Description and Remedy

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
