Xerox WorkCentre 5230A User Manual

Fault Codes
399
016-719 Unable to process PCL print data due to insufficient print page buffer memory.
Increase the print page buffer.
016-720 The PCL print data contains an invalid command. Check the print data, and then
try again.
016-721 A print error occurred. The Auto Tray Switching setting conflicts with the Paper
Type Priority settings. When the Auto Tray Switching feature is enabled, select
an option other than [Auto Paper Off] for trays on the [Paper Type Priority]
screen.
016-722 The specified staple position is not supported. Change the staple position, and
try again.
016-723 The specified hole-punch position is not supported. Change the hole-punch
position, and try again.
016-724 The specified staple and hole-punch positions are not a valid combination.
016-725 A scanned document saved in a mailbox could not be converted to fax data
using the job flow sheet. Send the document not by using the Job Flow Sheets
service, but by using Fax service.
016-726 The printer language was not selected automatically. The probable causes are
as follows:
• PostScript data was sent to the machine, but the PostScript Kit was not
installed on the machine.
• PDF data was sent directly to the machine using the lpr command, but the
HDD was defective. Contact the Xerox Welcome Center.
• PCL data was sent to the machine, but the optional emulation kit was not
installed on the machine.
016-727 The Save to Mailbox job was cancelled, because there was no data for the job.
Check if the document is blank.
016-728 The TIFF file contains unsupported tags. Check the print data.
016-729 The TIFF file could not be printed, because the resolution of the TIFF file was
too high. Lower the resolution of the TIFF file, and try again.
016-731 The print job was interrupted. Try printing the data again.
016-732 The form specified in the emulation setting is not registered in the host
computer. Resend the form data.
016-733 The IP address after the @ character could not be obtained. Enter the e-mail
address correctly.
Or, the DNS Internet address after the @ character could not be resolved. Set
the DNS server address correctly.
016-734 Printing a simple transmission report failed. Set the [E-mail Receive Protocol] on
the sender’s end to [SMTP].
016-735 An attempt was made to print a job template while it was being updated. Wait a
while, and then try printing the template again.
016-736 A lock directory was not created.
• Check that there is space on the target disk.
• Check the access permissions.
• Delete any existing lock directory.
016-737 The lock directory was not deleted. Delete the lock directory.
Code Description and Remedy

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
