Xerox WorkCentre 5230A User Manual

15 Problem Solving
402
016-779 An error occurred during conversion processing of the scan image. Instruct
scanning again.
016-780 An error occurred on the disk during conversion processing of the scanned
image, probably due to a disk malfunction. For details on replacing the hard
disk, contact the Xerox Welcome Center.
016-781 Unable to connect to the server during file forwarding by a Network Scanning
server application. Ask the System Administrator to check the network and
server.
016-782 Unable to connect to the server. Verify the user login name, password and other
information that are entered.
016-783 Unable to find the specified server path during file forwarding by a Network
Scanning server application. Check the path name of the server currently set to
the job template.
016-784 A write to server error occurred during file forwarding by a Network Scanning
server application. Confirm that there is sufficient space in the directory on the
server, and that access rights are present.
016-785 The file could not be sent by a Network Scanning server application due to
insufficient space on the server. Delete unnecessary data from the server.
016-786 The scanned data could not be written due to insufficient space on the hard disk.
Delete unnecessary data, or initialize the hard disk if the saved data are not
needed.
016-787 The server IP address set to the job template is incorrect. Specify the correct job
template.
016-788 Failed to retrieve the file from the web browser. Take one of the following
actions, and then try retrieving again.
• Refresh the browser page.
• Restart the browser.
• Switch the machine off and then back on.
016-789 The mail processing was interrupted due to insufficient hard disk space. Lower
the image resolution or reduction/enlargement ratio, or divide the document into
smaller segments to send.
016-790 The number of the e-mails in the e-mail job exceeded the value specified in
[Maximum Split Count]. Take one of the following actions:
1. Lower the scan resolution for the e-mail job.
2. Lower the image magnification for the e-mail job.
3. Increase the value in [Maximum Data Size per E-mail].
016-791 Access to the destination for the Scan to PC service or to the Network Scanning
server application failed. Check if you are authorized to access the specified
destination or server.
016-792 A job history report was to be printed, but the specified job history could not be
retrieved. The specified job history is not available.
016-793 The hard disk has run out of space. Delete unnecessary data, or initialize the
hard disk if the saved data is not needed.
016-794 The media was incorrectly inserted. Insert the media correctly.
016-795
016-796
016-797
A read error occurred on the media. Check the contents stored on the media
using a computer.
Code Description and Remedy

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
