Xilinx ChipScope Pro User Manual

154 www.xilinx.com ChipScope Pro Software and Cores User Guide
UG029 (v14.3) October 16, 2012
Chapter 5: ChipScope Engine Tcl Interface
::chipscope::csejtag_target get_info
This subcommand retrieves information from a previously opened JTAG target.
Note: A JTAG target lock does not need to be obtained prior to calling this function.
Syntax
::chipscope::csejtag_target get_info handle
Arguments
Returns
A list in the format:
{target_name plugin_name fw_ver driver_ver plugin_ver vendor frequency
port full_name target_uid rawinfo target_flags}
Where:
Note: An exception is thrown if the subcommand fails.
Example
Obtain information about the current JTAG target.
%set targetInfo [::chipscope::csejtag_target get_info $handle]
Back to list of all CseJtag Tcl Commands
Table 5-26: Arguments for Subcommand ::chipscope::csejtag_target get_info
Argument Type Description
handle
Required
Handle to the session that is returned by
::chipscope::csejtag_session create.
Value Description
target_name The name of the JTAG target
plugin_name The plugin library name string
fw_ver The firmware version string
driver_ver The driver version string
plugin_ver The plugin version string
vendor The vendor string
frequency The frequency string
port The port string
full_name The full target name string
target_uid The target-unique ID string
rawinfo The raw target info string
target_flags The integer containing target-specific flags
