CseFpga Tcl Commands
::chipscope::csefpga_get_user_chain_count
Determines the number of USER scan chain registers in the target FPGA device.
Syntax
::chipscope::csefpga_get_user_chain_count handle idcode
Arguments
Returns
The number of USER scan chain registers in the device (0 if the device does not have any
USER scan chain registers).
An exception is thrown if the command fails.
Example
Get the number of USER scan chain registers supported by the device to which $idcode
refers.
%set numUserRegs [csefpga_get_user_chain_count $handle $idcode]
Back to list of all CseFpga Tcl Commands
Table 5-52: Arguments for Subcommand
::chipscope::csefpga_get_user_chain_count
Argument Type Description
handle
Required
Handle to the session that is returned by
::chipscope::csejtag_session create.
idcode IDCODE for the desired device.
