Xilinx ChipScope Pro User Manual

190 www.xilinx.com ChipScope Pro Software and Cores User Guide
UG029 (v14.3) October 16, 2012
Chapter 5: ChipScope Engine Tcl Interface
::chipscope::csefpga_get_sys_mon_reg
Reads from a System Monitor register.
Syntax
::chipscope::csefpga_get_sys_mon_reg handle deviceIndex hexAddress
Arguments
Returns
A data value (in hexadecimal) read from the System Monitor DRP register at address
hexAddress.
An exception is thrown if the command fails.
Example
For the second device in the JTAG chain, read the System Monitor register at address 0x07.
%set hexOutData [csefpga_get_sys_mon_reg $handle 1 7]
Back to list of all CseFpga Tcl Commands
Table 5-57: Arguments for Subcommand ::chipscope::csefpga_get_sys_mon_reg
Argument Type Description
handle
Required
Handle to the session that is returned by
::chipscope::csejtag_session create
deviceIndex Device index (0 to n-1) in the n-length JTAG chain.
hexAddress System Monitor DRP register address (in hexadecimal) to
be read from.
