Xilinx ChipScope Pro User Manual

198 www.xilinx.com ChipScope Pro Software and Cores User Guide
UG029 (v14.3) October 16, 2012
Chapter 5: ChipScope Engine Tcl Interface
::chipscope::csevio_init_core
Initializes global variables associated with the target VIO core.
Syntax
::chipscope::csevio_init_core handle [list deviceIndex userRegNumber
coreIndex]
Arguments
Returns
An exception is thrown if the command fails.
Example
Initialize the VIO core connected to ICON core inside fourth device on second USER
register is a VIO core
%set coreRef [list 3 2 0]
%csevio_init_core $handle $coreRef
Back to list of all CseVIO Tcl Commands
Table 5-64: Arguments for Subcommand ::chipscope::csevio_init_core
Argument Type Description
handle
Required
Handle to the session that is returned by
::chipscope::csejtag_session create
[list
deviceIndex
userRegNumber
coreIndex]
A list containing three elements:
• Device index (0 to n-1) in the n-length JTAG chain
• BSCAN block USER register number (starting with 1)
• Index for core unit. First core unit connected to ICON
has index 0.
