Chapter3: Board Component Descriptions
Table3‐25: J5 HPC FMC Section G/H Connections to FPGA U1
J5
Pin
Schematic Net Name
I/O
Standard
U1
FPGA
Pin
J5
Pin
Schematic Net Name
I/O
Standard
U1
FPGA
Pin
G2 NC NA NA H1 FMC_HPC0_VREF_A_M2C NA (3)
G3 NC NA NA H2 FMC_HPC0_PRSNT_M2C_B LVCMOS33
G6 FMC_HPC0_LA00_CC_P LVDS AD20 H4 FMC_HPC0_CLK0_M2C_P LVDS AB21
G7 FMC_HPC0_LA00_CC_N LVDS AE20 H5 FMC_HPC0_CLK0_M2C_N LVDS AB22
G9 FMC_HPC0_LA03_P LVDS AB17 H7 FMC_HPC0_LA02_P LVDS Y17
G10 FMC_HPC0_LA03_N LVDS AC17 H8 FMC_HPC0_LA02_N LVDS AA17
G12 FMC_HPC0_LA08_P LVDS AE17 H10 FMC_HPC0_LA04_P LVDS AA20
G13 FMC_HPC0_LA08_N LVDS AF17 H11 FMC_HPC0_LA04_N LVDS AB20
G15 FMC_HPC0_LA12_P LVDS AC22 H13 FMC_HPC0_LA07_P LVDS AD16
G16 FMC_HPC0_LA12_N LVDS AC23 H14 FMC_HPC0_LA07_N LVDS AE16
G18 FMC_HPC0_LA16_P LVDS AD24 H16 FMC_HPC0_LA11_P LVDS Y18
G19 FMC_HPC0_LA16_N LVDS AD25 H17 FMC_HPC0_LA11_N LVDS AA18
G21 FMC_HPC0_LA20_P LVDS AF24 H19 FMC_HPC0_LA15_P LVDS AB24
G22 FMC_HPC0_LA20_N LVDS AF25 H20 FMC_HPC0_LA15_N LVDS AC24
G24 FMC_HPC0_LA22_P LVDS AE25 H22 FMC_HPC0_LA19_P LVDS AC26
G25 FMC_HPC0_LA22_N LVDS AE26 H23 FMC_HPC0_LA19_N LVDS AD26
G27 NC NA NA H25 FMC_HPC0_LA21_P LVDS AB25
G28 NC NA NA H26 FMC_HPC0_LA21_N LVDS AB26
G30 NC NA NA H28 NC NA NA
G31 NC NA NA H29 NC NA NA
G33 NC NA NA H31 NC NA NA
G34 NC NA NA H32 NC NA NA
G36 NC NA NA H34 NC NA NA
G37 NC NA NA H35 NC NA NA
G39 VADJ _FMC_BUS H37 NC NA NA
H38 NC NA NA
H 4 0 V A D J _ FM C _BU S
