KCU116 Board User Guide 75
UG1239 (v1.2) September 28, 2018 www.xilinx.com
Chapter3: Board Component Descriptions
The KCU116 evaluation board uses power regulators and PMBus compliant point of load
(POL) controllers from Maxim Integrated Circuits to supply the core and auxiliary voltages
listed in Table 3-27.
The VADJ_FMC rail is programmed to 1.80V by default. This rail powers the FMC HPC0 (J5)
VADJ pins and the XCKU5P FMC interface bank 64 (see Table 3-1, page 18).
Documentation describing PMBus programming for the Maxim InTune
™
power controllers
is available at the Maxim website [Ref 34]. The PCB layout and power system design meet
the recommended criteria described in the UltraScale Architecture PCB Design User Guide
(UG583) [Ref 14].
Table3‐27: Onboard Power System Devices
Rail Name
Power System Regulators
INA226 Power
Monitor
Schematic
Page
Number
Ref. Des. Device Type Vout (V) Max. I (A) Addr. Addr. Ref. Des.
VCCINT U47 MAX15301 0.85 40 0x13 0X40 U79 45
VCCBRAM U7 MAX15303 0.85 6 0x14 0x41 U81 46
VCCAUX U6 MAX15303 1.80 3 0x15 0x42 U80 47
VCC1V2 U10 MAX15303 1.20 2 0x16 0x43 U84 48
VCC1V8 U144 MAX15303 1.80 3 0x12 0x4B U176 49
VCC3V3 U9 MAX15303 3.30 5 0x17 0x44 U16 50
VADJ_FMC U63 MAX15303 1.80 10 0x18 0x45 U65 51
MGTAVCC U95 MAX20751 0.90 6 0x72 0x46 U74 52
MGTAVTT U96 MAX20751 1.20 6 0x73 0x47 U75 53
MGTVCCAUX U14 MAX8869E 1.81 1 NA NA NA 54
UTIL_3V3 U49 MAX15301 3.30 20 0x1A NA NA 55
SYS_5V0 U8 MAX17502 5.00 1 NA NA NA 56
SYS_1V0 U155 MAX15053 1.00 2 NA NA NA 57
SYS_1V8 U159 MAX15027 1.80 1 NA NA NA 57
SYS_2V5 U156 MAX15053 2.50 2 NA NA NA 57
DDR4_VTT U35 TPS51200 0.60 3 NA NA NA 58
