Yamaha 55DEHD - Propeller shaft housing

6-7
LOWR
6885J11
Lower unit
Propeller shaft housing
105 N·m (10.5 kgf·m, 77.4 ft·lb)
6886030E
No. Part name Q’ty Remarks
1 Shift plunger 1
2 Shift slider 1
3 Spring 1
4 Dog clutch 1
5 Cross pin 1
6 Spring 1
7 Propeller shaft 1
8 Reverse gear shim —
9 Reverse gear 1
10 Washer 1
11 O-ring 1
12 Ball bearing 1
13 Propeller shaft housing 1
14 Straight key 1
15 Needle bearing 1
16 Oil seal 2
17 Ring nut 1
Not reusable
Not reusable
Not reusable
Not reusable
