Yamaha 55DEHD - Removing the Control Lever and Throttle Cam

6885J11
5-12
9
8
7
6
5
4
3
2
1
Power unit
3. Disconnect the Ignition coil leads 6, and
then remove the ignition coils 7.
4. Remove the CDI unit bracket 8, ground
lead 9, collars 0 and grommets q.
5. Remove the starter relay w, PTT relay e
(ET), Rectifier Regulator r and CDI unit
t from the CDI unit bracket.
6. Remove the starter motor bolts y, and
then remove the starter motor u.
7. Remove the control link i, then remove
the stator assembly o, pulser coil
assembly p and retainer a.
Removing the control lever and
throttle cam
1. Remove the throttle link rod 1, control
lever 1 2, control lever 2 3 and throttle
cam 4.
7
6
B/W
B
68850130
r
t
w
e
68850140
68850160
i
p
a
o
9
0
q
q
8
68850150
y
u
68850165
6885076A
1
2
3
4
