Yamaha 55DEHD - Fuel line

FUEL
4-3
6885J11
Fuel system
Fuel line
6884030E
No. Part name Q’ty Remarks
1 Fuel joint 1
2 Bolt 1 M6 × 20 mm
3 Clip 14
4 Fuel hose 1
5 Fuel hose 1
6 Fuel filter assembly 1
7 Bolt 1 M6 × 14 mm
8 Bracket 1
9 Nut 1
10 Fuel hose 1
11 Joint 2 M6 × 40 mm
12 Fuel hose 1
13 Fuel hose 1
14 Fuel hose 1
15 Fuel hose 1
16 Gasket 1
17 Fuel pump assembly 1
Not reusable
