Yamaha 55DEHD - Assembling the Propeller Shaft Assembly

6885J11
6-12
9
8
7
6
5
4
3
2
1
Propeller shaft housing
Assembling the propeller shaft
assembly
1. Install the spring 1, dog clutch 2, shift
slider 3, cross pin 4, and then install the
shift plunger 5 temporarily.
NOTE:
9 Align the hole a of the dog clutch 2, hole
b of shift slider 3 with the slot c of the
propeller shaft and then install the dog
clutch 2.
9 Install the dog clutch 2 with the “F” mark
facing toward the forward gear.
2. Install the spring 6 onto the dog clutch
2.
1
2
3
a
c
5
b
4
68860160
6
2
6
68860170
