GEN
INFO
Symbol
The symbols below are designed to indicate the content of a chapter.
General information Fuel system Bracket unit
Specification Power unit Electrical system
Periodic check and adjustment
Lower unit Troubleshooting
Symbols 1 to 6 indicate specific data.
1 Special tool
2 Specified oil or fluid
3 Specified engine speed
4 Specified tightening torque
5 Specified measurement
6 Specified electrical value
(resistance, voltage, electric current)
Symbols 7 to e in an exploded diagram or illustration indicate the grade of lubricant and the lubri-
cation point.
7 Apply Yamaha 2-stroke motor oil
8 Apply gear oil
9 Apply water resistant grease (Yamaha grease A)
0 Apply molybdenum disulfide grease
q Apply corrosion resistant grease
(Yamaha grease D)
w Apply low temperature resistant grease
(Yamaha grease C)
e Apply injector grease
Symbols r to o in an exploded diagram or illustration indicate the type of sealant or locking agent
and the application point.
r Apply Gasket Maker
t Apply ThreeBond 1104J
y Apply LOCTITE 271 (red)
u Apply LOCTITE 242 (blue)
i Apply LOCTITE 572
o Apply silicone sealant
FUEL BRKT
SPEC POWR ELEC
CHK
ADJ
LOWR
TRBL
SHTG
123456
78 0qwe
rtyuio
