Yamaha 55DEHD - Electrical component

6885J11
8-2
9
8
7
6
5
4
3
2
1
Checking the electrical component / Electrical component
Electrical component
Starboard view
55DEHD, 75AEHD, 85AEHD
1
2
3
4
5
6
7
8
9
0
q
w
e
r
y
t
u
B
R
R
R
Br
Y/R
B
P
L
u
u
B / W
G
R
W
L
P
Br
B
y
1
e
B
B/W
B/W
P
B
G
R
G/W
G/W
G
B
B/W
B
Br
R
2
3
6
0
B
R
6888010E
1 Ignition coil #1
2 Ignition coil #2
3 Ignition coil #3
4 Stator assembly
5 Pulser coil assembly
6 CDI unit
7 Starter motor
8 Engine start switch
9 Engine stop lanyard
switch
0 Starter relay
q Fuse (20A)
w Neutral switch
e Rectifier Regulator
r Warning indicator
t Thermoswitch
y 10P-coupler
u Spark plug
B : Black
Br : Brown
G : Green
L : Blue
P : Pink
R : Red
W : White
B/W : Black/white
G/W : Green/white
Y/R : Yellow/red
