BRKT
7-47
6885J11
Bracket unit
6887150E
4 N·m (0.4 kgf·m, 3.0 ft·lb)
No. Part name Q’ty Remarks
1 Screw 2 ø5 × 10 mm
2 Trim spring 1
3 Up-relief spring 1
4 Valve support pin 1
5 Relief valve seal 1
6 Relief valve seat 1
7 O-ring 1
8 Filter 1
9 Valve lock screw 1
10 O-ring 1
11 Ball 1
12 Washer 1
13 Main valve seal 1
Not reusable
Not reusable
