Yamaha 55DEHD - Page 34

SPEC
2-9
6885J11
Specification
Item Unit
Model
55DEHD 75AEHD 75AED 75AET
PTT system
Trim sensor resistance Ω —
168.3–288.3
at 20°C (68°F) (P–B)
Trim sensor setting resistance Ω — 9–11
at 20°C (68°F) (P–B)
Fluid type — ATF
Dexron
2
Motor type — 6H102
Output kW — 0.3
Brushes
Standard length mm (in) — 9.75
(0.384)
Wear limit mm (in) — 5.5 (0.22)
Commutator
Standard diameter mm (in) — 22.0 (0.87)
Wear limit mm (in) — 21.0 (0.83)
Standard undercut mm (in) — 1.8
(0.07)
Wear limit mm (in) — 1.3
(0.05)
Hydraulic pressure (down) MPa (kgf/cm
2
) — 2.2–3.8
(22-38)
Hydraulic pressure (up) MPa (kgf/cm
2
) — 9–11
(90–110)
