Tightening torque
Part to be tightened Thread size
Tightening torques
N·m kgf·mft·lb
PTT unit (ET)
PTT motor mount bolt M6 7 0.7 5.2
Reservoir mount bolt M6 7 0.7 5.2
Reservoir cap — 7 0.7 5.2
Main valve — 11 1.1 8.1
Trim spring screw — 4 0.4 3.0
Valve lock screw — 4 0.4 3.0
Manual valve — 3 0.3 2.2
Pipe joint — 15 1.5 11.1
Pipe joint — 20 2.0 14.8
Stator mount screw (PTT motor) — 3.4 0.34 2.5
Gear pump bolt M4 4 0.4 3.0
Tilt ram — 65 6.5 47.9
Tilt cylinder end screw — 90 9.0 66.4
Tilt piston bolt M6 13 1.3 9.6
Trim cylinder end screw — 160 16 118
Electrical
Negative battery terminal bolt M8 30 3.0 22.1
Positive battery terminal nut — 9 0.9 6.6
Positive terminal nut — 4 0.4 3.0
Starter relay terminal nut — 4 0.4 3.0
CDI unit bracket mount bolt M6 7 0.7 5.2
Starter motor mount bolt M8 30 3.0 22.1
