Yamaha 55DEHD - Page 95

6885J11
5-8
9
8
7
6
5
4
3
2
1
Power unit
30 N·m (3.0 kgf·m, 22.1 ft·lb)
30 N·m (3.0 kgf·m, 22.1 ft·lb)
9 N·m (0.9 kgf·m, 6.6 ft·lb)
30 N·m (3.0 kgf·m, 22.1 ft·lb)
6885050E
No. Part name Q’ty Remarks
1 Bolt 3 M8 × 30 mm
2 Negative battery cable 1
3 Nut 1
4 Spring washer 1
5 Positive battery lead 1
6 Starter motor 1
6885J11_05 07.9.26 15:44 Page 11
