Yamaha F100B - Page 107

60C5D11
5-14
1
2
3
4
5
6
7
8
9
No. Part name Q’ty Remarks
1 Starter motor 1
2 Ignition coil 2
3 Starter motor lead 1 Black/white
4 Starter motor lead 1 Black
5 Washer 2
6Nut 2
7Bolt 3 M8
×
45 mm
8Bolt 1 M6
×
20 mm
9 Ground lead 3
10 Ignition coil lead 2
11 Bolt 4 M6
×
30 mm
12 Spark plug cap 4
13 Screw 5
14 Cover 1
15 Timing belt 1
16 Drive sprocket 1
17 Driven sprocket 2
18 Clip 1
19 Cooling water hose 1
20 Plastic tie 1
Not reusable
21 Bolt 2 M6
×
16 mm
22 Bracket 1
23 Bolt 2 M10
×
35 mm
24 Washer 2
25 Pin 2
26 Spring 1
27 Bolt 1 M10
×
45 mm
28 Tensioner 1
29 Nut 1
30 Retaining plate 1
31 Woodruff key 1
Timing belt and sprockets
