Yamaha F100B - Page 331

62Y5A11
9-10
1
2
3
4
5
6
7
8
9
(Lubricating system)
Check the oil pump for debris or
oil leaks.
Check the engine oil level.
Check the oil pressure.
Check the oil pressure switch.
Clean or replace the respective
parts.
At specified
level?
Out of specifi-
cation?
Debris or leaks?
Check the oil pas-
sage.
Yes
No
Yes
No
Yes
Yes
No
No
Add engine oil to the correct
level.
Replace the oil pressure switch.
Replace the CDI unit.
Good condition?
Power unit
