TRBL
SHTG
Troubleshooting
9-11
62Y5A11
Bracket unit
9
Symptom: Power trim and tilt unit does not operate.
Listen for the operation sound
of the power trim and tilt relay.
Listen for the operation sound
of the power trim and tilt motor.
Check that the manual valve is
closed.
Check the power trim and tilt
fluid level.
Check the power trim and tilt
motor.
Replace the power trim and tilt
relay.
Close the valve.
Can 12 V be
obtained?
Can 12 V be
obtained?
Can the oper-
ation sound
be heard?
Can the oper-
ation sound
be heard?
Replace the power
trim and tilt relay.
Check for continuity
between the battery,
relays, and switch.
Check the voltage between the
blue (L) lead and green (G)
lead.
Check the voltage between each terminal.
• Between the sky blue (Sb) lead and black (B) lead.
• Between the light green (Lg) lead and black (B) lead.
Is it closed?
Yes
Yes
Yes
Yes
No
No
No
No
No
Yes
Continued on next page.
