Yamaha F100B - Page 333

62Y5A11
9-12
1
2
3
4
5
6
7
8
9
Check the fluid passages for
clogs or debris.
Clean the passages.
Check the internal parts (valves,
pistons, gears, etc.).
Clean or replace the filters.Debris or dirt?
No
Yes
No
Yes
Add fluid to the correct level.
At specified
level?
Yes
No
Disassemble the power trim and
tilt unit, and then check the filter
for debris or dirt.
Clogs or debris?
Measure the hydraulic pressure.
(for F100B)
Check the power trim and tilt
unit for leaks.
Out of specifi-
cation?
Yes
No
Bracket unit
