INTAKE SYSTEM
FUEL
4-9
EXPLODED DIAGRAM
1
2
3
4
6
7
7
5
8
9
10
11
11
13
14
12
12
8 Nm (0.8 m•kg, 5.8 ft•lb)
8 Nm (0.8 m•kg, 5.8 ft•lb)
M6 x 25 mm
M6 x 90 mm
2
5
3
4
8
1
a
b
c
REMOVAL AND INSTALLATION CHART
Step
6
7
8
9
10
11
12
13
14
Q’ty
2
2
1
1
1
2
2
1
1
Service points
Reverse the removal steps for installation.
Procedure/Part name
Grommet
Bolt with washer
Intake silencer ass’y
Carburetor ass’y
Spacer
Gasket
Bolt with washer
Intake manifold
Gasket
