Yamaha F4A - Thermostat

E
THERMOSTAT
POWR
THERMOSTAT
EXPLODED DIAGRAM
5
6
4
3
2
1
8 Nm (0.8 m•kg, 5.8 ft•lb)
M6 x 20 mm
2
7
5-22
REMOVAL AND INSTALLATION CHART
Step
1
2
3
4
5
6
7
Q’ty
1
3
1
1
1
1
1
Service points
Follow the left “Step” for removal.
Reverse the removal steps for installation.
Not reusable
Procedure/Part name
THERMOSTAT REMOVAL
Oil level plug
Hose
Bolt with washer (thermostat cover)
Thermostat cover
Gasket (thermostat)
Thermostat
Screw (cylinder anode)
Cylinder anode
