Yamaha F4A - Drive Shaft, Forward Gear and Shift Rod

E
DRIVE SHAFT, FORWARD GEAR AND SHIFT ROD
LOWR
DRIVE SHAFT, FORWARD GEAR AND SHIFT ROD
EXPLODED DIAGRAM
2
3
4
5
1
6
8
7
9
10
6-16
REMOVAL AND INSTALLATION CHART
Step
1
2
3
Q’ty
1
1
1
Service points
Follow the left “Step” for removal.
NOTE:
When removing the pinion gear, pull up
the drive shaft slightly.
Procedure/Part name
DRIVE SHAFT, FORWARD GEAR AND
SHAFT ROD REMOVAL
Propeller shaft ass’y
Water pump ass’y
Plate (water pump)
Shift rod
Circlip (pinion gear)
Pinion gear
