Yamaha F4A - Dimensions; Outboard Dimension

2-7
E
SPEC
MAINTENANCE SPECIFICATIONS
L1 mm 375.4
(in) (14.78)
L2 mm 141.3
(in) (5.56)
L3 mm 341.6
(in) (13.45)
L4 mm 259.2
(in) (10.20)
L5 :S mm 70.8
(in) (2.79)
:L mm 92
(in) (3.6)
L6 :S mm 614.1
(in) (24.18)
:L mm 727.9
(in) (28.66)
L7 mm 341.9
(in) (13.46)
L8 mm 147.7
(in) (5.81)
L10 mm 63.3
(in) (2.49)
H1 :S mm 643.0
(in) (25.31)
:L mm 770.0
(in) (30.31)
H2 mm 386.0
(in) (15.20)
H3 mm 104.3
(in) (4.11)
H4 :S mm 435.1
(in) (17.13)
:L mm 562.1
(in) (22.13)
H5 mm 583.3
(in) (22.96)
H6 :S mm 498.2
(in) (19.61)
:L mm 441.8
(in) (17.39)
H7 mm 173.6
(in) (6.83)
H8 mm 3.5
(in) (0.14)
H9 mm 510.5
(in) (20.10)
H10 mm 38.9
(in) (1.53)
W1 mm 136.6
(in) (5.38)
W2 mm 224.4
(in) (8.83)
A1 degree 360
A2* degree 63.5
DIMENSIONS
Outboard dimension
H6
H1
H4
H5
H9
H2
H7
L8
L7 L6
L3
W2
W1
L2 L1
H10
H8
L4
A2
L5
L10
H3
A1
*Tilt lock
Symbol
World wide
USA/CANADA
Unit
Model(s)
F4A
F4
