1 Flywheel rotor ass’y
2 Ignitor ass’y
3 High tension cord
4 Spark plug cap
5 Engine stop switch lead
6 Engine stop switch
A Pass the engine stop switch
lead into the bottom cowling
port side slit.
B Clamp the engine stop
switch lead by the clamp on
the bottom cowling.
C Ground the cylinder body.
D Clamp the high-tension cord
to the clamp on the bottom
cowling, using the clamp
provided.
8-1
