Yamaha F4A - Bearings Inspection; Lower Casing Cap Oil Seal Removal; Lower Casing Cap;Propeller Shaft Bearing Removal; Slide Hammer Set

Lower casing cap oil seal removal
1. Remove:
9Oil seals 1
Lower casing cap/Propeller shaft bearing
removal
1. Remove:
9Ball bearing 1
A For USA and CANADA
B Except for USA and CANADA
E
LOWER CASING CAP ASS’Y
LOWR
1
2
3
4
1
5
1
6-13
Slide hammer set 2:
YB-06096
Stopper guide plate 3:
90890-06501
Bearing puller 4:
90890-06535
Stopper guide stand 5:
90890-06538
Slide hammer set:
YB-06096
Stopper guide plate:
90890-06501
Bearing puller:
90890-06535
Stopper guide stand:
90890-06538
SERVICE POINTS
Bearings inspection
1. Inspect:
9Bearing
Pitting/Rumbling ® Replace.
NOTE:
Turn the bearing by fingers, and check the
bearing pitching
A
B
