Yamaha F4A - Service Points; Fuel Filter Inspection; Fuel Filter Installation

E
FUEL PUMP AND FUEL FILTER
FUEL
4-5
a
2
3
1
SERVICE POINTS
Fuel filter inspection
1. Inspect:
9Fuel filter
Crack/Leak/Clog ® Replace.
Fuel filter installation
1. Install:
9Fuel filter 1
cC
The arrow mark on the fuel filter must
face towards the fuel pump.
2. Install:
9Clamp a
NOTE:
After connecting the fuel filter 1, clamp
the choke wire 3 to fuel hose 2 using the
hose clamp a.
