Yamaha F4A - Oil Splasher Gear and Oil Seal Housing

E
CRANKCASE, CRANKSHAFT AND CAMSHAFT
POWR
OIL SPLASHER GEAR AND OIL SEAL HOUSING
EXPLODED DIAGRAM
1
2
4
1
2
3
2
4
5
3
5-28
REMOVAL AND INSTALLATION CHART
Step
1
2
3
4
5
1
2
3
4
Q’ty
1
2
1
1
1
1
1
2
1
Service points
Follow the left ”Step” for removal.
Reverse the removal steps for installation.
Follow the left “Step” for disassembly.
Reverse the disassembly steps for assembly .
Not reusable
Not reusable
Procedure/Part name
OIL SPLASHER GEAR REMOVAL
Gasket (crankcase)
Dowel pin
Bolt with washer (oil splasher gear)
Oil splasher gear
Crankcase
OIL SEAL HOUSING ASS’Y
DISASSEMBLY
O-ring
Oil seal
Oil seal
Oil seal housing
