Yamaha F4A - Page 130

E
RECOIL STARTER
POWR
EXPLODED DIAGRAM
1
2
7
3
3
4
4
5
9
q
6
w
e
8
0
6.5 Nm (0.65 m•kg, 47 ft•lb)
5-3
REMOVAL AND INSTALLATION CHART
Step
0
q
w
e
Q’ty
1
1
1
1
Service points
Reverse the disassembly steps for assembly.
Procedure/Part name
Starter handle
Start-in-protection lever
Rubber seal
Starter case
