E
LOWER CASING CAP ASS’Y, REVERSE GEAR AND
PROPELLER SHAFT
LOWR
EXPLODED DIAGRAM
3
3
1
2
2
8 Nm (0.8 m•kg, 5.8 ft•lb)
M6 x 16 mm
1
6-8
REMOVAL AND INSTALLATION CHART
Step
1
2
3
Q’ty
1
2
1
Service points
Follow the left ”Step” for removal.
Reverse the disassembly steps for assembly.
Procedure/Part name
PROPELLER SHAFT WITH
REVERSE GEAR DISASSEMBLY
Reverse gear
Thrust washer
Propeller shaft ass’y
