Yamaha F4A - Page 240

E
DRIVE SHAFT, FORWARD GEAR AND SHIFT ROD
LOWR
EXPLODED DIAGRAM
2
3
4
5
1
6
8
7
9
10
6-17
REMOVAL AND INSTALLATION CHART
Step
4
5
6
7
8
9
10
Q’ty
1
1
1
1
2
1
1
Service points
Reverse the removal steps for installation.
Not reusable
Procedure/Part name
Plate washer
Drive shaft
Forward gear
Ball bearing (forward gear)
Oil seal (drive shaft)
Upper bushing
Lower bushing
