E
CARRYING HANDLE AND BOTTOM COWLING
BRKT
EXPLODED DIAGRAM
8
10
9
6
7
2
2
4
3
5
M6 x 25 mm
M6 x 25 mm
M6 x 16 mm
M6 x 16 mm
15
13
15
11
14
12
1
a
b
a
7-2
REMOVAL AND INSTALLATION CHART
Step
6
7
8
9
10
11
12
13
14
15
Q’ty
1
1
4
3
1
1
1
1
1
1
Service points
Reverse the removal steps for installation.
Procedure/Part name
Screw (shift lever)
Shift lever
Bolt with washer (carrying handle 1)
Bolt with washer (bottom cowling 1)
Carrying handle 1 ass’y
Screw
Fuel cock ass’y
Bolt with washer
Fuel joint ass’y
Bottom cowling 1 ass’y
