E
STEERING HANDLE
BRKT
EXPLODED DIAGRAM
1
2
3
y
5
6
7
8
9
4
0
q
w
e
r
t
7-5
REMOVAL AND INSTALLATION CHART
Step
1
2
3
4
5
6
7
8
Q’ty
1
2
1
1
1
1
1
1
Service points
Follow the left “Step” for disassembly.
Procedure/Part name
STEERING HANDLE DISASSEMBLY
Steering handle ass’y
Wave washer
Metal washer
Collar
Cotter pin
Friction adjusting screw
Screw
Steering grip
Washer
