Yamaha F4A - Fuel Pump and Fuel Filter

E
FUEL TANK, FUEL COCK AND FUEL JOINT
FUEL
4-2
EXPLODED DIAGRAM
1
2
2
3
3
3
6
M6 x 35 mm
M6 x 35 mm
5
4
8
7
9
REMOVAL AND INSTALLATION CHART
Step
2
3
4
5
6
7
8
9
Q’ty
3
3
1
1
1
1
1
1
Service points
NOTE
When removing the collar, lift the
starter case then remove from the fuel
tank.
Reverse the removal steps for installation.
Procedure/Part name
Bolt with washer (
starter case and fuel tank )
Collar
Fuel hose (fuel tank-to-fuel cock)
Fuel strainer
Fuel tank ass’y
Fuel hose (fuel joint-to-fuel cock)
Fuel cock ass’y
Fuel joint ass’y
