[Parameter]
type : Interface type
Interface type Description
port Physical interface
vlan VLAN interface
sa Static logical interface
po LACP logical interface
index : Index number
Interface ID Description
S.X
Specifies the stack ID (S) of the physical
interface, and the number printed on the chassis
(X). * The SWR2311P is fixed as stack ID=1.
<1－4094> Specify the VLAN ID.
<1－96> Speciffy the static logical interface number.
<1－127> Specify the LACP logical interface number.
[Input mode]
unprivileged EXEC mode, priviledged EXEC mode
[Description]
Shows the status of the interface specified by ifname. If ifname is omitted, shows the status of all interfaces.
The following items are shown.
Item Description
Interface Interface name
Link is
Link status *2 (if shutdown, shows the
cause)
•
If shutdown is specified : (by
shutdown)
• If port error is detected : (by err-
disable)
Hardware is Interface type (e.g., Ethernet, VLAN)
HW addr Physical (MAC) address *1
Description Description of interface
ifIndex Interface index number
MRU Maximum Receive Unit *4
ARP ageing timeout
ARP timeout time (time that ARP
entries are maintained) *3
Speed-Duplex
Speed and duplex mode settings, and
operating status *1
Auto MDI/MDIX Auto MDI/MDIX enabled/disabled *1
IPv4 address
IP address/mask length *3 (shown only
if IP address is set)
broadcast
IP broadcast address *3 (shown only if
IP address is set)
Switchport mode
Mode of the switchport
• access : untagged
Command Reference | Interface control | 117
