Item Description
- Set IP DSCP (Pre-marking setting : DSCP value)
- Set CoS-Queue (Specify egress queue : CoS
- Set IP-DSCP-Queue (Specify egress queue : DSCP)
Police Metering/policing/remarking setting
* For details, refer to the following
Details of metering, policing, and remarking settings are as follows.
Item Description
Aggregator-Police Name Name of aggregate policer (only if
specified)
Mode Metering algorithm (SrTCM/TrTCM)
Shown only for SrTCM average rate Traffic rate (kbits/sec)
burst size Burst size of conformant token bucket
(kBytes)
excess burst size Burst size of excess token bucket
(kBytes)
Shown only for TrTCM average rate Traffic rate (kbits/sec)
peak rate Peak traffic rate (kbits/sec)
burst size Burst size of conformant token bucket
(kBytes)
peak burst size Burst size of peak token bucket (kBytes)
yellow-action Action for bandwidth class Yellow
(transmit/drop/remark)
red-action Action for bandwidth class Red (drop/
remark)
• Of the various items in the "Match" and the "Set", only the single item that has been specified is shown.
•
The "Match", the "Set", and the "Police" are not shown if the corresponding command (match, set, police) has not been
specified.
[Note]
In order to execute this command, QoS must be enabled.
[Example]
Show information for policy map "policy1".
SWR2311P#show policy-map policy1
Policy-Map Name: policy1
State: attached
Class-Map Name: class1
Qos-Access-List Name: 1
Police: Mode: SrTCM
average rate (48 Kbits/sec)
burst size (12 KBytes)
excess burst size (12 KBytes)
yellow-action (Remark [DSCP:10])
red-action (Drop)
9.2.40 Show map status
[Syntax]
show qos map-status type
[name]
