ELECTRIC STARTING SYSTEM
5-15
1
2
3
4
5
6
7
8
9
10
ELECTRICAL
ELECTRIC STARTING SYSTEM
REMOVING THE STARTER MOTOR (Equipped models)
Order Job/Parts to remove Q’ty Remarks
Removing the starter motor Remove the parts in the order listed.
1 Starter motor assembly 1
1
16 N・m (1.6 kgf・m, 12 lb・ft)
16 N・m (1.6 kgf・m, 12 lb・ft)
