GENERAL TORQUE SPECIFICATIONS
7-10
1
2
3
4
5
6
7
8
9
10
SPECIFICATIONS
GENERAL TORQUE SPECIFICATIONS
This chart specifies torque for standard fasteners with standard I.S.O. pitch threads. Torque specifi-
cations for special components or assemblies are inclu
ded in the applicable sections of this book. To
avoid warpage, tighten multi fastener assemblies in a crisscross fashion, in progressive stages, until
full torque is reached. Unless otherwise specifications call for clean, dry threads. Components
should be at room temperature.
Thread size
Tightening torque
N·m kgf·m lb·ft
M4 2.0 0.20 1.5
M5 3.0 0.30 2.2
M6 7 0.7 5.2
M7 10 1.0 7.4
M8 15 1.5 11
M10 30 3.0 22
M12 60 6.0 44
