Yamaha MX360 - Spark Plug Inspection

PERIODIC MAINTENANCE
2-4
1
2
3
4
5
6
7
8
9
10
PERIODIC CHECKS AND ADJUSTMENTS
4.
Install:
• Spark plug
TIP
To prevent threads from being damaged, temporally
tighten “a” the spark plug before tightening it to the speci-
fied torque “b”.
FUEL LEAKAGE
1. Check:
• Leakage
Check at fuel tank, fuel cock, fuel hose, and carbu-
retor
ENGINE OIL LEAKAGE
1.
Place the multi-purpose engine on a level surface.
2.
Check the areas outside of the engine for oil leakage.
Oil leakage  Replace the gasket, oil seal, or O-ring.
ENGINE OIL LEVEL
1.
Remove:
• Oil filler cap “1”
TIP
• This engine is equipped with two oil filler caps. Use
whichever side is accessible.
• The amount of engine oil should be checked by looking
a
t the reference surface as opposed to using the oil filler
cap stick.
a
b
Spark plug:
20 N·m (2.0 kgf·m, 15 lb·ft)
T
R
.
.
Replace fuel hose every four years.
NOTICE
1
