MUFFLER
3-7
1
2
3
4
5
6
7
8
9
10
ENGINE
MUFFLER
EQUIPPED MODELS
Order Job/Parts to remove Q’ty Remarks
Removing the muffler Remove the parts in the order listed.
Fuel tank
Refer to “FUEL TANK (Equipped models)” on
page 3-5.
1 Muffler 1
2 Gasket 1
3 Muffler cover 1
4 Spark arrester 1
3
1
2
4
10 N・m (1.0 kgf・m, 7.4 lb・ft)
10 N・m (1.0 kgf・m, 7.4 lb・ft)
20 N・m (2.0 kgf・m, 15 lb・ft)
20 N・m (2.0 kgf・m, 15 lb・ft)
3.5 N・m (0.35 kgf・m, 2.6 lb・ft)
